Used helicopter sales

2015 AW109SP GrandNew

VIP October 2015 AW109SP presented in immaculate condition as a previous UK VVIP government aircraft.

Aircraft is on an engine PBH programme, andcomprises a very high spec including EVS, CVR/FDR, emergency float provisions, wire strike protection and satcom.

Maintained to the highest standard by Sloane Helicopters from new, an authorised Leonardo Service Centre and has had a recently completed 3,200 hour inspection.

Price: Please Enquire

Year of Construction: 2015

Total Time Since New: 3,035

Engine: Pratt & Whitney PW207C turbo shaft engines

Avionics:

Single Pilot, Dual Control IFR Avionic Package:

  • Dual pilot flight/navigation EFIS (PFD and MFD) with embedded FMS, Synthetic Vision (SVS), HTAWS (Helicopter Terrain Awareness and Warning System), slip indicator and Remote Bug Panel (RBP)
  • Co-pilot flight/navigation EFIS (2 displays) with embedded FMS, Synthetic Vision (SVS), HTAWS (Helicopter Terrain Awareness and Warning System), slip indicator and remote Bug Panel (RBP)
  • Reversionary Control Panel (RCP)
  • EFIS pilot/co-pilot navigation synchronization switch (FMS data)
  • Electronic Standby Instrument system (ESIS)
  • Second Radio Management System (RMS) RTU-4210 Collins
  • Second VHF/AM VHF-40000E Collins
  • VOR/ILS/ADF NAV-4000 Collins
  • DME DME-4000 Collins
  • Radio Altimeter ALT-4000 Collins
  • Second Attitude Heading Reference System (AHRS)
  • Second Air Data Unit (ADU)
  • Pilot GPS/SBAS Chelton interfaced to EFIS/FMS
  • Co-pilot GPS/SBAS Chelton interfaced to EFIS/FMS
  • Digital Audio Control System (DACS) COBHAM additional cockpit panel
  • 4-axis dual duplex digital AFCS with integrated Flight Director
  • Second electronic clock
  • Second magnetic compass indicator
  • ELT C406-N HM Artex (with Navigation Interface Module embedded)
  • Dual controls

Additional Avionic Equipment

  • 8.4 inch central display
  • Euronav
  • Traffic Advisory System TAS-620 Avydine (presented on EFIS)
  • Weather radar RDR 2000 Bendix/King (presented on EFIS)
  • UHF/AM KTR-909

Additional Equipment:

  • Electrically operated passenger steps (LH and RH)
  • 213 USgal crash-resistant fuel system (in lieu of 152 USG)
  • 2.3m baggage compartment extension
  • Emergency floats provision
  • Wire strike protection
  • Penny & Giles Cockpit Voice / Flight Data Recorder (CVR/FDR)
  • Enhanced Vision System (EVS)
  • Aircell Satcom Iridium ST3100
  • 24 VDC 33Ah nickel-cadmium battery (20 cells in lieu of 19 cells)

Interior:

VIP Deluxe Interior - Six Seats

  • All seats crash-resistant covered with leather or fabric/leather
  • Three fwd facing seats (aft bench) and three aft facing seats (central bench)
  • Forward facing armrests
  • 4-point shoulder harness for all passenger seats
  • Super silent soundproofing
  • Liners leather/leatherette covered
  • Acoustic screen around doors
  • Cabin double layer acrylic windows
  • Decoration trim with metal inserts
  • Intercommunication system for passengers
  • Headset Bose ANR type (qty six)
  • Cabin loudspeakers (qty two)
  • Reading lights, emergency lights, floor courtesy lights
  • Passenger hooks (qty four)
  • Upper and lower air vents
  • Floor carpeting with carpeting protection
  • Seat covers
  • Air conditioning ECS

Exterior:

Finishing in white with red stripe
